- 20 -
live part in the worst-case rated operating condition when used as intended.
Interface
DVC
PV input interface
DVCC
AC output interface
DVCC
SD card interface
DVCA
RS485 interface
DVCA
CT interface
DVCA
Logic interface
DVCA
WiFi/GPRS/Ethernet interface
DVCA
4.1. Electrical connection
Figure4-1 Shows the flowchart for connecting cables to the inverter.
4.2. Connecting PGND Cables
Connect the inverter to the grounding electrode using protection ground
(PGND) cables for grounding purpose.
The inverter is transformer-less, requires the positive pole and negative
pole of the PV array are NOT grounded. Otherwise it will cause inverter
failure. In the PV power system, all non current carrying metal parts
(such as: PV module frame, PV rack, combiner box enclosure, inverter
enclosure) should be connected to earth.
Attention
Start
Connect PGND
cable
Connect DC
input cable
Connect AC output
power cable
Connect communication
cables (not mandatory)
End
