Power
10
The system power circuit breaker must only be assessable by Authorized
Personal.
This device must be suitably rated for the installation; see electrical ratings
guidance.
The conductor size for the inputs must be selected based on the rating of
their corresponding over-current device and in accordance with local and
national regulations.
Battery
The GCM contains a lithium battery that is used to retain the real-time clock.
The battery on the GCM shall be replaced by a trained technician, and the
replacement battery must be UL approved.
FOR BURGLAR ALARM INSTALLATIONS:
The iSTAR Ultra is not provided with backup power. An external power
supply must be provided with the following characteristics:
• UL 603 and UL 294 Listed
Minimum four hours of standby power
Tyco / Software House Advanced Power Supply (apS) meets these
requirements. Several apS units, wired in parallel, will provide 12Vdc
output at [units x 3.75A] in excess of four hours when using the
supplied 17AH batteries.
All Burglar Alarm and Intrusion Zone inputs must be supervised and
have Triggers configured to Alarm upon Tamper.
At least one RM2L-4000 reader must be in each area/partition for
signal acknowledgement.
There are multiple power inputs to the unit. To completely
de-energize the unit, disconnect ALL power sources.
NOTE
For UL Listed products, a UL 603 and UL 294 listed power supply must be
used.
