This section provides the power requirements for the iSTAR Ultra and its
components.
Electrical
Electrical ratings are dependant upon the configuration.
GCM
 Input
12 Vdc , 1.5 - 4.5A max.
 Output
RS485: 11-11.14 Vdc , 1.5A max. each
ACM
 Input
• Vreader: 12 Vdc , 12.5A max.
• Vlock1: 0 - 30 Vdc , 12A max.
• Vlock2: 0 - 30 Vdc , 12A max.
 Output
• RS485/Wiegand/AUX: 11.64 Vdc , 1.5A max. each
• Primary Wet Relay Out: 0 - 30 Vdc , 0.75A max. each
• Primary Dry Relay Out: 30 Vdc/Vac, 5A max. each
• Secondary Wet Relay Out: 0 - 30 Vdc , 0.75A max. each
• Secondary Wet Relay Out: 30 Vdc/Vac, 1A max. each
Additional Power
Requirements
 An external over-current protection device (i.e. circuit breaker) must be
installed in a secure location readily accessible to a service person.
 Circuit Breakers need to be sized so that its normal sourced current does not
exceed 80% of the circuit breaker rating.
NOTE
The GCM RS-485 ports have not been evaluated by UL.
The RS-485 ports are power limited on the GCM.
NOTE
The Weigand, RS-485, and Aux ports are power limited on the ACM.
