Access Control Module
29
ACM LED Functions
Table 10. ACM LED Functions
LED Function Comment
DS21 Main Power - Reader Power - J4 12 Vdc
DS52 Main Power - LOCK 1 - J2 12 or 24 Vdc
DS54 Main Power - LOCK 2 - J3 12 or 24 Vdc
Relays
DS14 Relay 1 Activated Primary Relay
DS15 Relay 2 Activated Primary Relay
DS13 Relay 3 Activated Primary Relay
DS8 Relay 4 Activated Primary Relay
DS31 Relay 5 Activated Primary Relay
DS32 Relay 6 Activated Primary Relay
DS30 Relay 7 Activated Primary Relay
DS29 Relay 8 Activated Primary Relay
DS34 Relay 9 Activated Secondary Relay
DS33 Relay 10 Activated Secondary Relay
DS35 Relay 11 Activated Secondary Relay
DS36 Relay 12 Activated Secondary Relay
DS39 Relay 13 Activated Secondary Relay
DS40 Relay 14 Activated Secondary Relay
DS38 Relay 15 Activated Secondary Relay
DS37 Relay 16 Activated Secondary Relay
Wiegand Ports
DS12 Wiegand 1 Powered
DS53 Wiegand 2 Powered
DS17 Wiegand 3 Powered
DS19 Wiegand 4 Powered
DS49 Wiegand 5 Powered
DS48 Wiegand 6 Powered
DS47 Wiegand 7 Powered
DS55 Wiegand 8 Powered
