sol-ark 5K - Common Battery Application Notes

April 21, 2021 39
F46
Parallel_Aux_Fault
Cannot communicate with other parallel systems. Check Master = 1, Slaves are 2-9, ethernet cables are
connected.
F47
AC_OverFreq_Fault
Grid over Frequency (common in power outages) causes disconnect. Will self-reset when grid stabilizes.
F48
AC_UnderFreq_Fault
Grid under Frequency (common in power outages) causes disconnect. Will self-reset when grid stabilizes.
F49
AC_U_GridCurr_DcHigh_Fault
Contact Sol-Ark.com
F55
DC_VoltHigh_Fault
PV maybe higher than 500V. Battery voltage should not be above 59V or 63V (depending on model).
F56
DC_VoltLow_Fault
Batteries are overly discharged or Lithium BMS has shutdown. If battery settings are off, this can also
happen.
F58
BMS communication fault
Sol-Ark is programmed to BMS Lithium Battery Mode but cannot communicate with a BMS
F60
Gen_Volt_or_Fre_Fault
Generator Voltage or Frequency went outside allowable range
F61
Button_Manual_OFF
Parallel Slave system was turned off without turning off Master
F63
ARC_Fault
Can be a bad PV connector/connection. And sometimes a false alarm due to powerful lightning storms.
F64
Heatsink_HighTemp_Fault
Check the built-in fans are running, ambient temp may be too high
Common Battery Application Notes
Sol-Ark PCC-230 Battery
Batt Capacity: 230Ah x #Parallel_Batteries
(1 parallel = 4 Batt in series, 2 = 8 Batt, 3 = 12 Batt, 4 =16 Batt)
Max A Charge: 100A x #Parallel_Batteries
Max A Discharge: 100A x #Parallel_Batteries
Max A Grid Charge: 50A x #Parallel_Batteries
TEMPCO: -5mV/C/Cell
Float V: 53.6V
Absorption V: 57.6V
Equalization V: 57.6V
Equalization Days: 30
Equalization Duration: 3 Hours
Recommended Shutdown V / Percentage: 47.0V & 20%
Recommended Low Batt V / Percentage: 47.5V & 35%
Recommended Restart V / Percentage: 52.0V & 50%
Battery Resistance: 35mOhms (8 Batt) or 25mOhms (16 Batt)
Battery Charge Efficiency: 99%
Battery Empty Voltage: 45V
Generation 2 Fortress Battery-eVault18.5
Batt Capacity: 360Ah x #Parallel_Batteries
Max A Charge: 150A (100A for life) x #Parallel_Batteries
Max A Discharge: 160A x #Parallel_Batteries
Max A Grid Charge: 100A x #Parallel_Batteries
TEMPCO: 0mV/C/Cell
BMS Lithium Batt: Not Selected
Float V: 54.4V
Absorption V: 54.4V
Equalization V: 55.5V
Equalization Days: 30
Equalization Duration: 1 Hours (tops off battery)
Recommended Shutdown V / Percentage: 51.3V & 20%
Recommended Low Batt V / Percentage: 51.7V & 30%
Recommended Restart V / Percentage: 51.9V & 40%
Battery Resistance: 5mOhms
Battery Charge Efficiency: 99%
Battery Empty Voltage: 47V
Time
Watts
SOC
GridCharge
1:00AM
1500*Par_Batts
70%
5:00AM
1500*Par_Batts
70%
9:00AM
1500*Par_Batts
70%
1:00PM
1500*Par_Batts
100%
4:00PM
1500*Par_Batts
70%
9:00PM
1500*Par_Batts
70%
Time
Watts
SOC
GridCharge
1:00AM
6000*Par_Batts
40%
5:00AM
6000*Par_Batts
40%
9:00AM
6000*Par_Batts
40%
1:00PM
6000*Par_Batts
40%
5:00PM
6000*Par_Batts
40%
9:00PM
6000*Par_Batts
40%
These settings will charge the batteries off solar only.
Discharge the batteries down to a maximum of 70% full.
Limited To Home mode will not sell to the grid from the
batteries (only the home will use battery power). The
100% time slot is to ensure that the batteries are
properly cycled each day.
These settings will charge the batteries off solar only.
Discharge the batteries down to a maximum of 40% full.
Limited To Home mode will not sell to the grid from the
batteries (only the home will use battery power).
