SE3800H-
US
SE5000H-
US
SE6000H-
US
SE7600H-
US
SE11400H-
US
Unit
INPUT
Maximum DC
Power
5900 7750 9300 11800 17650 W
Transformer-less,
Ungrounded
Yes
Maximum Input
Voltage
480 Vdc
Nominal DC Input
Voltage
380 400 Vdc
Maximum Input
Current
10.5 13.5 16.5 20 30.5 Adc
Max. Input Short
Circuit Current
45 Adc
Reverse-Polarity
Protection
Yes
Ground-Fault
Isolation
Detection
600 kΩ Sensitivity
Maximum
Inverter Efficiency
99.2 %
CEC Weighted
Efficiency
99 %
Nighttime Power
Consumption
< 2.5 W
ADDITIONAL FEATURES
Supported
Communication
Interfaces
RS485, Ethernet, ZigBee (optional), Cellular (Optional)
Revenue Grade
Data, ANSI C12.20
Optional
(1)
Rapid Shutdown
- NEC 2014 and
2017 690.12
Automatic Rapid Shutdown upon AC grid disconnect
(1)
Revenue grade inverter P/N: SExxxxH-US000xxW2.
Technical Specifications - EV Charging Single Phase Inverter (North America)
85
EV Charging Single Phase Inverter Guide MAN-01-00588-1.1
