SolarEdge EV Series


SE3800H-
US
SE5000H-
US
SE6000H-
US
SE7600H-
US
SE11400H-
US
Unit
STANDARD COMPLIANCE
Safety
UL1741, UL1741 SA, UL1699B, CSA C22.2, Canadian AFCI
according to T.I.L. M-07

Grid Connection
Standards
IEEE1547, Rule 21, Rule14 (HI) 
Emissions FCC part15 class B 
RoHS Yes 
INSTALLATION SPECIFICATIONS
AC output
conduit size /
AWG range
1” maximum/ 14-6 AWG
1”
maximum/
14-4 AWG

DC input conduit
size / # of strings
/ AWG range
1” maximum/ 1-2 strings / 14-6 AWG
1” maximum
/ 1-3 strings
/ 14-6 AWG

Dimensions with
Connection Unit
with Safety
Switch (HxWxD)
17.7 x 14.6 x 6.8 / 450 x 370 x 174
21.3 x 14.6 x
7.3 / 540 x
370 x 185
in/mm
Weight with
Connection Unit
with Safety
Switch
22 / 10 25.1/11.4  26.2 / 11.9 38.8 / 17.6 lb / kg
Noise < 25  < 50 dBA
Cooling Natural Convection 
Operating
Temperature
Range,
-40 to +140 / -40 to +60
(1)
°F/ °C
Protection Rating NEMA 4X(Inverter with Connection Unit with Safety Switch) 

Default Trip Limits and Times According to IEEE1547
NOTE
The inverters are equipped with adjustable utility protective function set-
points, and can be aggregated above 30kW on a single Point of Common
Connection. The default settings are in compliance with IEEE1547. Utility
authorization is required to change these set-points.
(1)
Full power up to at least 50°C/122°F. For power de-rating information refer to :
https://www.solaredge.com/sites/default/files/se-temperature-derating-note-na.pdf
EV Charging Single Phase Inverter Guide MAN-01-00588-1.1
