SolarEdge EV Series User Manual

EV Charger Ground Connection
Monitoring
Yes, continuous 
EV Charger Configuration
Via the monitoring app; Ethernet or ZigBee
connection is required
(1)

STANDARD COMPLIANCE
Safety
UL2594, UL2231-1, UL2231-2, NEC Article 625
compliant

EVCharger SAE J1772-2009 
INSTALLATION SPECIFICATIONS
EV Charger Connector SAE J1772-2009 
EV Charger Cable Length
(2)
25 / 7.6 ft/ m
EV Charger Cable Weight 12.5 / 5.7 lb / kg
EV Charger and Cable Operating
Temperature Range
-22 to +122 / -30 to +50 °F/ °C
Protection Rating (connected to
EV or with dust cap)
NEMA 3R 
(1)
Cellular connection may be used; requires a SIM card with a 1GB data plan that should be purchased from
a cellular provider.
(2)
EV Charger cable ordered separately.
EV Charging Single Phase Inverter Guide MAN-01-00588-1.1
88 EV Charger and EV Charger Cable Specifications

SolarEdge EV Series Specifications

General

AC Frequency	60 Hz
Protection Rating	IP65
AC Voltage	208/240 V
EV Charger Output Voltage	208/240 V
EV Charger Max. Output Current	32 A
Communication	Ethernet, Wi-Fi
Safety	UL1741
Operating Temperature Range	-25°C to 60°C
