25
L10US-IB20, L10US-IB40, L10US-IB60 L10US-IB00, L15US-IB40, L15US-IB60 L15US-
IB00, L20US-IB60, L20US-IB00 UPS
Figure 18 Muser5000 UPS ID setting page
CAUTION!
After changing the parallel system ID, the connection between Muser5000 and
the equipment might be interrupted. If it happens, re-connect in accordance
with the instruction above.
CAUTION!
Parallel cable cannot be connected when setting the parallel parameters.
• After setting the UPS systems needed to be paralleled, power off all the UPS systems.
Connect all the UPS systems in parallel cable installation, and then power on the UPS
systems.
