L10US-IB20, L10US-IB40, L10US-IB60 L10US-IB00, L15US-IB40, L15US-IB60 L15US-
IB00, L20US-IB60, L20US-IB00 UPS
4.3. LCD control panel
4.3.1. Overview
Figure 19 LCD control panel introduction
Table 5 LCD and LED display
1
Fault LED
2
Bypass mode LED
3
Battery mode LED
4
Inverter work LED
5
LCD display
