SolarEdge L10US-IB20 - 5 Appendix 1: Specifications; Table 10 Specifications

65
L10US-IB20, L10US-IB40, L10US-IB60 L10US-IB00, L15US-IB40, L15US-IB60 L15US-
IB00, L20US-IB60, L20US-IB00 UPS
5. Appendix 1: Specifications
Table 10 Specifications
Model
L10US
L15US
L20US
General
Capacity (VA/Watts)
10k / 10k
15k / 15k
20k /20k
Input and output type
4w/4w+PE
Design rating (power
module technical rating)
10kW power
module x1
15kW power
module x1
20kW power
module x1
Efficiency
(with linear
load)
Normal mode
Up to 93%
Up to 93.5%
Up to 93.5%
ECO mode
Up to 98%
Short circuit capacity Icc
(KAIC)
10
Parallel system (integrated
parallel / Static Switch
Cubicle)
Up to 2
Configuratio
ns or
architecture
Standalone
Yes
Parallel
Yes
Frequency
converter
Yes
Bus
Synchronizati
on without
external box
No
Input
THDI (100% Load)
<3%
PF (100% R Load)
>0.99
Frequency tolerance
40-70Hz
