69
L10US-IB20, L10US-IB40, L10US-IB60 L10US-IB00, L15US-IB40, L15US-IB60 L15US-
IB00, L20US-IB60, L20US-IB00 UPS
Model
L10US
L15US
L20US
Physical
Dimension D×W×H (mm)
See Table 3
Service
Access
Back
500mm/ 19.6’’
Right side
1000mm/ 39.3’’
Left side
1000mm/ 39.3’’
Front
1000mm/ 39.3’’
Top
500mm/ 19.6’’
Termination
input
Rear side
output
Rear side
DC/Battery
Rear side
Protection degree (Standard
IP)
IP20
PCB
Conformal coating
Installation
Wheels and leveling feet
Net weight
See Table 3
Standards
Approving Agency
TUV RHEINLAND CHINA & CCIC
Agency Standard Tested
UL1778 5th Edition
Canadian Approvals
CSA 22.2-107.3-14
EMI Approvals
FCC Part15 Subpart B Class A/ ANSI C63.4 2014
