The communication board has a standard RJ45 terminal block for Ethernet connection,
a 6-pin terminal block for RS485 connection, and an 8-pin connector for power control
devices.
The SolarEdge Cellular Plug-in can be connected to the communication board for
optional wireless connection.
Figure 18: Communication board connectors
EV Charging Single Phase Inverter MAN-01-00629-1.2
55 Communication Connectors
