SolarEdge SE5000H-AU

EV Charger and EV Charger Cable Specifications
NOTE
The EV Charging inverter and EV Charger cable are ordered separately.
OUTPUT- AC (EV CHARGER)  
Charging Mode
AC Mode 3
Connection to the SolarEdge monitoring
platform is required for first EV charging

Minimum charge rate
(1)
1.5 kW
Rated AC Power Output(grid &
PV)
(2)
7400
W
Nominal AC Output Voltage 230 Vac
Nominal AC Frequency 50 / 60 Hz
Maximum Continuous Output
Current @230V
32 Aac
Residual Current Detector (AC) 30
mA rms
ADDITIONAL FEATURES
EV Charger Status LEDs, Fault
Indicator
Yes 
EV Charger Ground Connection
Monitoring
Yes, continuous 
EV Charger Configuration
Via the monitoring app; Ethernet or Wi-Fi
connection is required
(3)

EV Charger Unplugging
Detection
 Yes, current termination according to IEC
62196

STANDARD COMPLIANCE
Safety IEC 61851, IEC 62752:2016 
EVCharger IEC 62196 
INSTALLATION SPECIFICATIONS
EV Charger Connector IEC 62196 Type 1 /Type 2 
EV Charger Cable Length
(4)
7.6 (4.5 option) m
(1)
Minimum charge rate is in compliance with IEC61851-1 and J1772™ FEB2016 standards.
(2)
Minimum charge rate 1.5 kW
(3)
Cellular connection may be used; requires a SIM card with a 1GB data plan that should be
purchased from a cellular provider
(4)
EV Charger cable ordered separately.
Technical Specifications - EV Charging Single Phase Inverter - (Australia) 86
EV Charging Single Phase Inverter MAN-01-00629-1.2
