Verifying the Connection
1.
Check the status screens:
HA devices
status, showing the device name and state: ON, OFF, or an asterisk (*),
which indicates no communication with the device:
H A D e v i c e s S t a t e :
S E - S - P L G 0 1 1 < O N >
Communication
status, showing the number of communicating HAdevices (under
Prot) and the number of detected devices (under ##):
w w w w w D e v P r o t # #
R S 4 8 5 - 1 < - - - > < - - > < -
>
Z i g B e e < H A > <
1 > < 1 >
2.
To check the device details, from the device configuration screen, select Device
Info. The following screen is displayed:
M A C : x x x x x x x x x x x
L a s t s e e n : < D D : H H >
M F G : S o l a r E d g e
M o d e l : S E - S - P L G
P o w e r [ W ] : 0
MAC: the full MACaddress of the device
Last seen: The date and time when the device communicated with the inverter
MFG: The device manufacturer
Model: The device model type
Power [W]: The energy delivered to the load
LEDIndications
The device has a bi-color LED (red/ green) that provides information about its operation
status:
LEDfunction Indication
Solid green (2 seconds), flashing green (2
seconds)
Reset
Flashing red No ZigBee association with the inverter
Flashing green ZigBee association in process
Smart Energy Socket
20 Verifying the Connection
