Specifications
ELECTRICAL SERVICE
SEHAZB-SCKT-MTR-XX
(1)
Operating Voltage Range - Line
to Neutral
90 - 250 Vac
AC Frequency 50/60 Hz
Maximum Active Power
Measurement
2.5 kW
Maximum Load Current 13 A
COMMUNICATION
Supported Communication
Protocol
ZigBee Home Automation
Nominal Transmit Power 3 dBm
Operating Frequency Range 2.4 - 2.5 GHz
Outdoor (LOS) Range 400 m
Indoor Range
(2)
50 m
STANDARD COMPLIANCE
Radio
ETSI EN 300 328 V 1.8.1, ETSI EN 301 489-1,
ETSI EN 301 489-17
Safety EN 60335-1, EN 60335-2-30, EN 50371
Immunity EN 55014-2
Emissions EN 55014-1, EN 61000-3-2, EN 61000-3-3
INSTALLATION SPECIFICATIONS
Operating Temperature Range 0 to +50 °C
Protection Rating IP30
Dimensions (H x W x D) 110 x 50 x 40 mm
(1)
Multiple plug types for various sockets: XX = GB, DE, FR, IT
(2)
Approximate values. May differ depending on specific installation conditions.
Configuration 25
Smart Energy Socket
