7.5 Technical data SolarMax 2000S/3000S
SolarMax 2000S SolarMax 3000S
Input side (DC)
Maximum generator output *) 2300 W
STC 3300 WSTC
Regelbereich 100…550 VDC
Maximum input voltage 600 VDC
Input current 0...11 ADC 0...11 ADC
Output side (AC)
Rated output 1800 W 2500 W
Maximum output 1980 VA 2750 VA
Nominal mains voltage / range 230 V
AC / 184...300 VAC
Power factor (PF) > 0.98
Nominal mains frequency/range 50 Hz / 45...55 Hz
Harmonic distortion at rated output < 3 %
System data
Maximum efficiency 97 % 97 %
European efficiency 95.4 % @ 400 V
DC
94.6 % @ 300 VDC
95.5 % @ 400 VDC
94.9 % @ 300 VDC
Ambient temperature –20 °C…+ 60 °C
Rated output up to ambient
temperature of
+ 45 °C
Relative humidity 0…98 %, no condensation
Protection type IP 54
Circuit type digital sine wave controller, transformerless, two-stage
(no galvanic isolation)
Heat dissipation convection / fan (fan exchangeable from outside)
Display graphic LC display 128 x 64 pixels, with background
illumination and status LED
Operation three push buttons
DC insulation switch integrated DC insulation switch according to VDE 0100-712
CE-compliant according to EN 50178, EN 61000-6-2, EN 61000-6-3, EN 61000-3-2,
EN 61000-3-3
Mains monitoring VDE 0126-1-1
Fault current monitoring VDE 0126-1-1
Mark of conformity “Type approved” TÜV Rheinland
Additional standards DK 5940, RD 661
Data logger data logger for energy yield, peak output and operating
duration for the last 31 days, 12 months and 10 years
Data communication RS 485 / Ethernet
Fault alarm contact M12 connector with relay as N/C contact / N/O contact
Dimensions (WxHxD) 545 x 290 x 185 mm
Weight 13 kg 13 kg
Casing aluminium, cover powder-coated
*) Recommended overdimensioning15 % (ISE Fraunhofer study)
All rights, amendments and errors reserved.
