Parameter Description
IP address
Con guration of the Ethernet interface (see also Section 7.1 “Con gura-
tion of the data communications interfaces”)
Netmask
TCP Port
Status relay De nition how the status signalling contact functions (see section 4.7.8
“Status signalling contact (optional)”)
Status relay delay Setting the switching delay of the status signalling contact
NOTE
■ The selection of the display language is independent of the selected country
setting.
■ If you link several inverters and accessory components into one MaxComm
communications network you must assign a unique address to each device in the
network.
6.4.2.7 Information
This menu shows the following information:
■ Device type (SM2000S, SM3000S, SM4200S, SM6000S)
■ Firmware version
■ Date of commissioning
■ Webadresse (www.solarmax.com)
Use the
and keys to move through the menu. Press the left button to return
to the Main menu.
6.4.2.8 Auto Test
During the Auto Test procedure in mains mode the trigger threshold for AC voltage and
frequency monitoring is varied linearly with a ramp of ≤ 0.05 Hz/s and ≤ 0.05 Vn/s (Vn
= 230 Vac, only available for country setting “Italy”). At some point during the test the
threshold will coincide with the current measured value, leading to triggering of the moni-
toring intervention. After each test step the values of the trigger thresholds, delay times,
current measured frequency and AC voltage values, and the standard threshold trigger
value are displayed.
