SolaX Power DataHub 1000 User Manual

DataHub 1000 User Manual
7
4.3 Installation of DI Signal Cable
DataHub can access DI signals such as remote control and alarms through the DI port.
D 1I
D 2I
D 3I
D 4I
Illustrate
8-10mm
terminal
DI1~DI4
12V
DI
1
2
3
4
12V
12V
12V
12V
Support pa ssive
dry co n tac t
s i g n al acc es s
marksocket
4.4 Installation of AI Signal Cable
Installation advice：
 It is recommended that the transmission distance does not exceed 10 m;
 AI port 0 and AI port 1 are connected to AI signal +, and GND is connected to AI signal–.
8-10mm8-10mm
GND
AI0~AI1
AI0
AI1
AI
0
1
GND
GND
Illustratemarksocket
Supports 0-12V voltage input
4.5 Installation of DO Signal Cable
The DO port supports 30V signal voltage in maximum. The contact of four-group output is on by default.
