c) Ethernet
There are two modes to obtain IP address: static and DHCP.
User can set the information about ethernet such as IP address, subnet mask
number, default gateway number and Mac address.
> IP Method
DHCP
Ethernet
Setting Setting
56
57
d) Work mode
>Mode Select
Force time use
Work Mode
> Charge
Start time 1
08:00
Work Mode
>Charger period 1
Charge From Grid
Disable
Work Mode
For “Force Time Use” mode, there are 8 parameters that needs to be set.
Charger start time1
Charger end time1
The start time of the rst charger period.
Charger start time2
Charger end time2
The end time of the rst charger period.
The start time of the second charger period.
The end time of the second charger period.
Parameter
Comment
There are 4 work modes for choice.
All these work modes is available for on-grid condition only:
e) Relay Control
Relay Control is an optional function which can control designated load
intelligently by consuming the surplus energy when feed in power reaches
certain value.
This function can only be achieved with solax product “Smart Plug”.
For specific operation, please refer to “ Smart Plug user manual”.
>Relay1 Setting
>Relay2 Setting
Relay Control
Battery will stop discharging to keep higher capacity when the
grid is on. when the power generated by PV is not enough, the
battery will discharge to supply the local loads too. And if still
not enough, the grid will power the local loads together.
This work mode applies to the area where suffering from
blackout regularly.
The priority of inverter output power is:
feeding to the grid supplying the load charging the
battery.
This work mode applies to the area with high feed-in tariff.
Self Use
(default)
Force Time Use
Back Up Mode
Feed in Priority
The PV generated power will be used to supply the local loads
first, then to charge the battery. The redundant power will
export to the public grid.
When there is no PV supplied, battery will discharge for local
loads first, and grid will supply power when the battery capacity
is not enough.
The priority of inverter output power is:
supplying the load charging the battery feeding to the grid
In this work mode the charging and discharging time can be set
flexibly, and it also allows to choose whether charge from the
grid or not. Other time it follows the priority of Self Use mode.
Parameter Comment
To Next Page
