Parameter Settings
27
Press Mode
To advance to
STOP PARAMATERS
Press Select
Then press
keys to set Soft Stop Curve
0 = Standard Curve
1!! = Pump Control Curve # 1
2!! = Pump Control Curve # 2
3!! = Pump Control Curve # 3
4 = Pump Control Curve 4 (Torque Control)
SOFT STOP CURVE
0 (STANDARD)
When setting Dip sw # 2 On for Tacho Mode,
Press
curve message changes to:
STOP TACHO GAIN
0 (MIN. GAIN)
Then press
keys to set Tacho gain:
0 = Minimum gain tacho, control
1!! = Second level tacho gain
2!! = Third level tacho gain
3!! = Fourth level tacho gain
4!! = Firth level tacho gain
5!! = Sixth level tacho gain
Note: Tacho Feedback is operational in its basic
form. Additional curves except for the
basic linear curve are optional. Consult
factory for correct tacho selection and
mechanical installation.
Press Select
Then press
keys to set Deceleration Time.
Range: 1-30 sec.
DEC. TIME
10 SEC.
Press Select
Then press
keys to set Final Torque during Soft
Stop.
Range: 0 – 10 (0 = min., 10 = max.)
FINAL TORQUE
0 (MIN)
Press Select
To store selected parameters, press
Store
key
STORE ENABLE
STOP PARAMETERS
When parameters have been correctly stored the LCD
displays:
DATA SAVED OK
This concludes STOP PARAMETERS setting.
Press Mode
To advance to (only when Dip Sw. # 1 is set to ON):
DUAL ADJUSTMENT
PARAMETERS
When selecting “Generator Mode” (Dip sw # 3 is On)
the following display appears instead of the above.
D. ADJ: GENERATOR
PARAMETERS
Press Select
Then press
keys to set DA: Initial Voltage.
Range: 10-50% of Un.
DA: INIT. VOLT.
30%
Press Select
Then press
keys to set DA: Current Limit.
Range: 100-400% of motor’s FLA.
DA: CUR. LIMIT
400% OF FLA
Press Select
Then press
keys to set DA: Acceleration Time.
Range: 1-30 sec.
DA: ACC. TIME
10 SEC.
Press Select
Then press
keys to set DA: Deceleration Time.
Range: 1-30 sec.
DA: DEC. TIME
10 SEC.
Press Select
Then press
keys to set DA: Motor FLA
Range: 50-100% of “STARTER FLC”
DA: MOTOR FLA
105 AMP.
Press Select
To store selected parameters, press Store key
STORE ENABLE
D.ADJ. PARAMETERS
When parameters have been correctly stored, the LCD
displays:
DATA SAVED OK
This concluded DUAL ADJUSTMENT
PARAMETERS setting.
