Appendix A - Physical Specication
Front to Back Depth 390.2 mm / 15.4"
Height (from table top inc. feet) 141.2 mm / 5.6"
Width 437.2 mm / 17.2" (Excluding Trim)
489.4 mm / 19.3" (Including Trim)
Power 70 Watts
Unboxed Weight 6.8 kg / 15.0 lbs (Console excluding PSU)
Boxed Size Width x Height x Depth
600 mm x 260 mm x 540 mm (23.6" x 10.2" x 21.3")
Boxed Weight 10.1 kg / 22 lbs
Note: All physical specication values are approximate.
Connector Details
Mono Channels
Microphone Inputs
3-pin XLR Male
Pin Description
1 0 V Chassis
2 Signal +ve (Hot)
3 Signal -ve (Cold)
Stereo Channels
Stereo Channel Line Inputs
1/4" TRS Jack Socket
Pin Description
Tip Signal +ve (Hot)
Ring Signal -ve (Cold)
Sleeve 0 V Chassis
Talkback Microphone Input
3-pin XLR Female
Pin Description
1 0 V Chassis
2 Signal +ve (Hot)
3 Signal -ve (Cold)
Line Inputs
1/4" TRS Jack Socket
Pin Description
Tip Signal +ve (Hot)
Ring Signal -ve (Cold)
Sleeve 0 V Chassis
External Inputs
Stereo External Line Inputs
1/4" TRS Jack Socket
Pin Description
Tip Signal +ve (Hot)
Ring Signal -ve (Cold)
Sleeve 0 V Chassis
Foldback/Stereo Cue Outputs
1/4" TRS Jack Socket
Pin Description
Tip Signal +ve (Hot)
Ring Signal -ve (Cold)
Sleeve 0 V Chassis
