Appendix B
43
Overall Channel Signal Chain Specications
Signal applied to Line Input of a mono channel, and routed to specied output by shortest path. All controls set at, out or at unity
gain as appropriate. Pan set to full left or right.
Measurement Conditions Value
Foldback, B-Bus & Main Output
Output Headroom into 600 Ω at onset of clipping
into 10 kΩ at onset of clipping
>24 dBu
>27.5 dBu
THD+Noise +20 dBu @ 1 kHz (lter 22 Hz to 22 kHz) < 0.0015 %
Frequency Response 20 Hz to 20 kHz
-3 dB high rolloff
+0.0/-0.2 dB
>80 kHz
Output Impedance 100 Ω
Pot centre detent accuracy: +/-1 dB, typically <0.5 dB
Overall Console Noise
Measured at main outputs, channels routed as required with pans / balance controls centred, using Line input with termination. All
controls set at, out or at unity gain as appropriate, channel and master faders calibrated for 0dB.
Measurement Conditions Value
Noise at Main Output 1 mono channel routed (all other muted)
All channels routed
<-90 dBu
(<–116 dB with respect to +26 dBu)
< –82.5 dBu
(<–108.5 dB with respect to +26 dBu)
ADC and DAC Converter
Measurements taken at 48 kHz
Measurement Conditions Value
Alignment Level 0 dBFS +24 dBu
THD+Noise DAC -10 dBFS @ 1 kHz (lter 22 Hz to 22 kHz)
ADC -4 dBFS @ 1 kHz (lter 22 Hz to 22 kHz)
0.001 %
0.0007 %
Dynamic Range DAC A-weighted
ADC A-weighted
117 dB
117 dB
Environmental Requirements
Temperature range:
Operating: +1 to 30 degrees Celsius.
Storage: -20 to 50 degrees Celsius.
