Solid State Logic BiG SiX User Manual

BiG SiX User Guide
Appendix A
40
Main Bus Outputs
1/4" TRS Jack Socket
Pin Description
Tip Signal +ve (Hot)
Ring Signal -ve (Cold)
Sleeve 0 V Chassis
Main Monitor Outputs
1/4" TRS Jack Socket
Pin Description
Tip Signal +ve (Hot)
Ring Signal -ve (Cold)
Sleeve 0 V Chassis
Bus B Outputs
1/4" TRS Jack Socket
Pin Description
Tip Signal +ve (Hot)
Ring Signal -ve (Cold)
Sleeve 0 V Chassis
Alternate Monitor Outputs
1/4" TRS Jack Socket
Pin Description
Tip Signal +ve (Hot)
Ring Signal -ve (Cold)
Sleeve 0 V Chassis
Insert Sends/Returns
1/4" TRS Jack Socket
Pin Description
Tip Signal +ve (Hot)
Ring Signal -ve (Cold)
Sleeve 0 V Chassis
DC Power Inlet
4-pin DIN Male
Pin Description
1,4 +15 V, 3.3 A
2,3 0 V Common
Shell Chassis
