BiG SiX User Guide
Introduction
1
Introduction
BiG SiX is a studio grade, SuperAnalogue mixing console that delivers all of the quality and exibility audio professionals expect
from an SSL console, but in a package that is designed to t the compact footprint needed for smaller personal studios. Its
design doesn't compromise on performance because of its size, but delivers a powerful set of professional features in a 9U 19"
rack width package.
BiG SiX incorporates professional quality A to D and D to A converters and a multi-channel USB DAW interface, however the
connections and signal ow is such that it can be used as a wholly analogue mixing console, without reliance on the digital
connection.
Audio Excellence
➤ Four SuperAnalogue wide gain range mic pres for pristine recording quality
➤ Four wide gain range stereo line inputs
➤ Individually switchable phantom power on each Mic Input
➤ Line level input with true HiZ (1 MΩ) impedance switch for passive coil inputs (e.g. guitar pickups)
➤ Four recording channels with fully balanced inserts, simple three band SSL EQ and Dynamics and true bypass processing
switching
➤ Fast, accurate peak response LED meters
➤ Inbuilt 16 channel high quality AD and DA Converters with USB-C interface for DAWs
Mixing Versatility
➤ 18 channel stereo SuperAnalogue summing
➤ Main bus with fully balanced insert
➤ Simplied SSL Bus Compressor
➤ 100 mm studio grade long throw faders
➤ Stereo Mix Bus Summing Input to cascade mixing consoles.
Application Flexibility
➤ A ‘proper’ foldback section with two stereo send/cue buses with talkback, local monitoring plus two stereo cue feeds
➤ Versatile B-Bus/Mute switching provides record and mix buses for simple overdubs
➤ Useful, exible signal routing and summing
➤ Versatile ‘summing’ monitor section with two external source selectors
➤ Two Headphone Outputs with separate source selectors
➤ ‘Listen mic compressor’ with exible routing for studio talkback or more creative applications
