ORIGIN User Guide
Appendix C
Channel Equaliser
Signal applied to Line Input and measured at the channel Insert Send. EQ switched in with EQ controls centred in Shelf mode.
Measurement Conditions Value
Output Headroom >+26.5 dBu at onset of clipping
THD+Noise +20 dBu @ 1 kHz (lter 22 Hz to 80 kHz) <0.003% at 20 dBu 1 kHz
<0.003% at 20 dBu 10 kHz
Noise <-80 dBu
Overall Channel Signal Chain Specications
Signal applied to Line Input of a channel and routed to specied output by shortest path. All controls set at, out or at unity gain
as appropriate. Pan set to full left or right.
Measurement Conditions Value
Auxiliary Send, Track Bus and Main Mix Bus Outputs
Output Headroom into 600Ω at onset of clipping
into 10kΩ at onset of clipping
>24 dBu
>26.5 dBu
THD+Noise +20dBu @ 1kHz (lter 22Hz to 80kHz) <0.0008% at 1 kHz
<0.0008% at 10 kHz
Frequency Response
Track Buses
Main Mix Bus
Auxilliary Buses
- 20 Hz to 20 kHz
- -3 dB high rolloff
- 20 Hz to 20 kHz
- -3 dB high rolloff
- 20 Hz to 20 kHz
- -3 dB high rolloff
+0/-0.3 dB
>70 kHz
+0/-0.3 dB
>70 kHz
+0/-0.3 dB
>70 kHz
Pot centre detent accuracy: +/-1 dB, typically <0.5 dB
