Crosstalk
Signal applied to Line Input of a mono channel, and routed to specied output by shortest path. All controls set at, out or at unity
gain as appropriate. Pan set to full left or right.
Measurement Conditions Value
Channel Muting 20 Hz to 20 kHz <-100 dB
Maximum Fader Attenuation 20 Hz to 20 kHz <-89 dB
Pan pot Isolation 20 Hz to 20 kHz <-55 dB
Routing
Channel to Main Mix <-94 dB from 20 Hz to 20 kHz
Routing
Channel to Track Buses Channel routed to all buses apart from one under test
Channel not routed
<-64dB from 20 Hz to 20 kHz
<-113dB from 20 Hz to 20 kHz
Mic Input -50dBu applied to Mic Input at maximum gain, measured at
Direct Output, Monitor path selected
<-95 dB
Overall Console Noise
Measured at main outputs, channels routed as required with pans / balance controls centred, using Line input with termination. All
controls set at, out or at unity gain as appropriate, channel and master faders calibrated for 0dB.
Measurement Conditions Value
Line to Mix
(Pan to centre)
1 channel routed
16 channels routed
24 channels routed
32 channels routed
<-93 dBu
<-85 dBu
<-83 dBu
<-80 dBu
Environmental Requirements
Temperature range:
Operating: +1 to 30 °C (+34 to 86 °F).
Storage: -20 to 50 °C (-4 to 122 °F).
