5.5 A dvanced Sett i n g s
N O TE :
To access to t h i s area i s f or f u lly q u ali f i ed and accredi ted tech ni ci an s only.
E n t er m enu “A dvan ced set t i ng s” ( P assw ord “001 0" ) .
Select “A dvanced Setti ng s.” f rom t h e M ai n M en u .
Th e screen w i ll req u i re t h e passw ord as below :
Inpu t P assw ord
X X X X
Fi g u re 5.1 7 E nter passw ord
Select A dvanced Sett i n g s f rom t h e M ai n Men u t o access th e f ollow i n g opti ons:
1 . Se l e c t Stand ard
2 . G rid Sw itc he s
3 . B atte ry C ontrol
4 . B ac ku p C ontrol
5 . Storage E ne rgy Se t
6 . STD . M od e Se ttings
7 . Softw are Upd ate
8 . E x port P ow e r Se t
9 . R e s e t P as s w ord
1 0 . R e s tart H M I
1 1 . Se l f Te s t C E I 0 - 2 1
1 2 . C om pe ns ation Se t
5.5. 1 Select i n g St andard
Th i s f u n ct i on i s u sed t o select t h e g ri d's ref eren ce standard.
YE S=<E NT> NO =<E SC >
St andard:G 98
Fi g u re 5.1 8
P ress t h e UP /D O W N k eys to select t h e st andard ( G 98, G 99, VD E 4 01 5, E N5054 9L,
C E I02 1 , A S4 777-1 5, NR S097, User-D ef , etc) .
P ress t h e E NTE R k ey t o con f i rm t h e setti n g .
P ress t h e E SC k ey t o cancel ch ang es an d retu rns t o previ ou s m enu .
For di f f erent cou n t ri es, th e g ri d standard needs to be set as di f f eren t accordi n g to local
req u i rem ent s. If t h ere i s any dou bt , please con su lt Soli s servi ce t ech ni ci ans f or detai ls.
N O TE
5.4 .4 C om m u n i cati on D at a
Th e screen sh ow s th e i nt ern al dat a of th e In vert er, w h i ch i s f or servi ce tech ni ci an s only.
01 -05: 00 00 00 00 00
06-1 0: 00 00 00 00 0 0
Fi g u re 5.1 5 C om m u n i cati on D ata
Th e yi eld prof i le i nclu des: E n erg y B attery, E n erg y G ri d and E nerg y B ack u p.
A ll t h e h i stori cal en erg y g en erati on records can be easi ly vi ew ed i n th i s secti on .
5.4 .5 Yi eld P rof i le
E n erg y B at t ery
E n erg y G ri d
Fi g u re 5.1 6 C om m u n i cati on D ata
.3 0. .3 1 .
