21
6.5 EPS Connection
If you want to use the energy storage system to power the house
(as a standalone system or during Grid failure), the EPS connector
should be used and the EPS function should be enabled in setup.
Otherwise you could leave the EPS port un-connected.
Before connecting, please make sure:
• The grid voltage and frequency must be in the permissible
range.
• External AC switches must be used on EPS connection to cut
off the inverter from EPS load when necessary.
Procedure:
STEP 1:
• Assemble the EPS connector.
• Make sure Live/Neutral/PE wire
is correct, please follow the
markings on the connector.
STEP 2:
• Connect the EPS plug to the
inverter. A “click” sound will
indicate firm connection.
