27
Position
Designation
A
EMS port communication status.
B
Total energy the inverter has produced.
C
Battery parameters, voltage and current are
displayed alternatively.
D
Direction of the battery energy.
E
BMS Status.
if this label is not shown, BMS Connections should
be checked.
F
SOC of the Battery.
G
PV panels parameters, voltage and current are
displayed alternatively.
H
PV panels status.
If there’s no PV voltage, this label will not be shown.
I
Total PV power generation
J
Default as current time, when an error occurred,
fault code will be displayed alternatively.
K
Default as current date, when an error occurred,
fault code will be displayed alternatively.
L
Direction of the grid power.
M
Grid status. If there’s no grid, this label will not be
shown.
N
Grid parameters, voltage and current are
displayed alternatively.
O
Direction of the load power. If PV Inverter is
installed, it could feed power back into the grid.
P
Indicating local load.
Q
Load parameters, voltage and current are
displayed alternatively.
R
Current power of the inverter.
