Chapter 2 Hardware Setup
Chapter 2 Hardware Setup
To Get things ready for Hardware setup !!!
1. We recommend to install your CPU before any other componentes. For
detailed installalation instructions of processor, you can also refer to the
pamphlet enclosed in your CPU package.
2. Installing a cooling fan with a good heatsink is a must for proper heat
dissipation for your CPU. Get ready an appropriate fan with heatsink for
proper installation. Inproper fan and installation will damage your CPU.
3. In case CPU Vcore, CPU clock or Frequency Ratio is adjustable onboard,
please follow the instructions described in the User manual for proper
setup. Incorrect setting will cause damage to your CPU.
The following topics are included in this chapter:
2-1 Pentium 4 CPU Installation
2-2 Pentium 4 CPU Fan Installation
2-3 Memory Installation
2-4 AGP 4X (Accelerated Graphics Port) Installation
2-5 HDD/FDD Installation
2-6 Jumper and Switch Settings
2-7 Other Connectors Configuration
2-8 IRQ Description
