85DR-C
4
CONTENT
Chapter 1 Specification ............................................................ 8
1-1 Mainboard Specifications ...........................................................9
1-1.1 CPU Socket .................................................................................... 9
1-1.2 Sysem Chipset Architecture ........................................................... 9
1-1.3 Memory .......................................................................................... 9
1-1.4 AWARD BIOS V6.0 ....................................................................... 9
1-1.5 Hardware Monitoring ..................................................................... 9
1-1.6 Sound Controller .......................................................................... 10
1-1.7 Multi-I/O Function ....................................................................... 10
1-1.8 Expansion Slots ............................................................................ 10
1-1.9 Accelerated Graphics port (AGP) Interface ................................. 10
1-1.10 FORM FACTOR ........................................................................ 10
1-1.11 Power Management .................................................................... 11
1-2 Mainboard Layout .....................................................................12
1-3 Chipset System Block Diagram ................................................13
Chapter 2 Hardware Setup .................................................... 15
2-1 Pentium 4 CPU Installation with Socket 478............................16
2-2 Pentium 4 CPU Fan Installation: ..............................................17
2-3 Memory Installation ..................................................................18
2-3.1 To Install DIMM Module ............................................................. 18
2-3.2 To Remove a DIMM: ................................................................... 18
2-4 AGP 4X (Accelerated Graphics Port) Installation ..................19
2-5 HDD/FDD Installation ..............................................................20
2-6 Jumper and Switch Settings ......................................................22
2-6.1 Switch 1 CPU Clock Select......................................................... 23
2-6.2 Factory Test (By JP2) ................................................................... 24
2-6.3 Memory Module Voltage Select (By JP3/JP4) ............................. 24
