Chapter 2 Hardware Setup
2-6.4 JP13 Memory Stick/Secure Digital Memory Card Reader Select
2-6.5 AGP Voltage Select (By JAGP1/JAGP2)
1.6V
1.7V
1.8V
Voltage AGP Select
1.5V
(default)
13
13
JAGP1
JAGP2
13
13
JAGP1
JAGP2
13
13
JAGP1
JAGP2
13
13
JAGP1
JAGP2
This jumper is designed on board for Memory Stick/Secure Digital Memory
Card Reader select for CMEM1 connector.
Memry Stick Reader (Default)
Secure Digital Memory Card
Reader
JP13
JP13
31
31
Memory Stick/Secure Digital Memory Card
Reader Select
CMEM1
MS/SD Cable
Secure Digital Memory Reader
Memory Stick Reader
Connection between CMEM1 connector and MS/SD Card Reade
r
