MIC-5010, MIC-5005 – USER MANUAL
20
Press the MENU button to navigate to the test
current and load time selection.
The buttons and are used to set the pa-
rameter value, while the and buttons move
to the next parameter.
The setting sequence is as follows:
charge time: 1 min...60 min,
charge voltage: 250 V, 500 V or 1 kV.
maximum charge current: 1,2 mA or 3 mA.
Note:
- In an environment with strong interferences the measurement may be affected by additional uncer-
tainty.
3.2 Low-voltage measurement of resistance (MIC-5010 only)
3.2.1 Measurement of resistance of protective conductors and equipotential
bonding with ±200 mA current
Set the rotary switch at the R
CONT
po-
sition.
The meter is ready for
measurement.
