3.5.2
RCD tripping time
Switch on the meter.
Set
the
rotary
switch
to
the
t
A
position
with
the
selected I
Δn
multiplic
ation factor.
Set the parameters according to the following algorithm and the rules for setting the general pa-
rameters.
I
Δn
◄►
Current
waveform
◄►
RCD type
◄►
U
L
◄►
Measurement
mode
◄►
I
Δn
x n
(for t
A
, U
B
,
R
E
mode)
▲
▼
▪ 10 mA
▪ 15
mA
▪ 30 mA
▪ 100 mA
▪ 300 mA
▪ 500 mA
general
purpose
short-time
delay
selective
▪ 12.5 V (for
)
▪ 25 V
▪ 50 V
▪ t
A
, U
B
, R
E
▪ U
B
, R
E
▪ 1/2
▪ 1
▪ 2
▪ 5
In I
Δn
x n, the multipliers 2 and 5 do not apply to I
Δn
= 300 mA and 500 m
A.
Connect the test leads as shown in the figure.
