MPI-506 – USER MANUAL
Press to read additional results.
R
CONT-
– resistance measured with 200 mA
negative polarity current
R
CONT+
– resistance measured with 200 mA
positive polarity current
Press START to start the next measurement
without disconnecting the test leads or to
measure the resistance above >100 Ω.
Additional information displayed by the meter
Tested facility is live. The measurement is blocked. Im-
mediately disconnect the meter from the facility (both
leads).
Message displayed after the measurement, it indicates
significant divergences between the partial measurements
(point ). The measurement result may include a large,
unspecified error. Possible causes:
too much disturbances in the measured object,
instability of the object or of the meter’s connection with
the object (unreliable galvanic connection).
Measurement range is exceeded.
