Sonomed 300A - Section 6 System Specifications; Physical; Electrical; Interface

Section 6 Specifications
Doc # 0300-A-1901-3D 6 - 1
PHYSICAL
Dimensions
Width
Depth
Height
239 mm 9.4”
225 mm 8.9”
71 mm 2.8”
Weight 2.7 kg 6.0 lbs
ELECTRICAL
Power Consumption 10.0 W (Typical)
Incoming Line
Voltage (±10%)
Frequency
120 VAC
60 Hz
230 VAC
50 Hz
Power Supply
DC Output
Current Output
13 VDC
750 mA
13 VDC
930 mA
ENVIRNOMENTAL
Operating Temperature
Operating Humidity
5 - 40°C (41 - 104°F)
10 - 90% Non-Condensing
Storage Temperature
Storage Humidity
-40 - 70°C (-40 - 158°F)
10 - 90% Non-Condensing
INTERFACE
DC Input 1-Pin Jack Connector
Foot Pedal 1-Pin Jack Connector
Probe Input 5-Pin Jack Connector with
Insertion Key
Printer Output 36-Pin Parallel Centronics
Connector
DISPLAY
Type LCD Backlit Display with
Touch Screen Overlay
Resolution 320 x 240 pixels (h x v)
Dimensions
Width
Height
115 mm 4.5”
86 mm 3.4”
Section 6
SPECIFICATIONS
PROBES
A-Scan Probes
Styles
Frequency
Focal Length
Fixation Light
Standard A-Probe
Soft-Touch A-Probe
10 MHz ± 10%
DC 22-27 mm / ST 22-27 mm
Internal Red LED
Pachymeter Probes
Styles
Frequency
Focal Length
Probe Tip Diameter
Straight Pachymeter Probe
Angled Pachymeter Probe
15 MHz ± 10%
0.5 mm
1.75 mm
PRINTER (OPTIONAL)
Model Seiko DPU-414
Type Thermal Printer
Paper Size
Width
Roll Diameter
110 mm 4.3”
50 mm 2.0”
ACCESSORIES
System
Item
300A 300P 300AP
PACSCAN™ Unit
• • •
Stylus Touch Pen
• • •
Foot Pedal
• • •
AC Adapter
• • •
Instruction Manual
• • •
A-Scan Probe
• •
Coupling Gel
• •
Pachymeter Probe
• •
Printer with Paper
•
Opt.
•
Carrying Case Optional
