Width
Position Settings | Width
(Only for video mode of HDMI, S-Video, composite and component inputs)
Adjusts total width of the image by stretching or shrinking.
Height
Position Settings | Height
(Only for video mode of HDMI, S-Video, composite and component inputs)
Adjusts total height of the image by stretching or shrinking.
Horizontal Start
Position Settings | Horizontal Start
(Only for video mode of HDMI, S-Video, composite and component inputs)
Changes the starting point of the image horizontally, without altering the height.
Vertical Start
Position Settings | Vertical Start
(Only for video mode of HDMI, S-Video, composite and component inputs)
Changes the starting point of the image vertically, without altering the width.
Auto Adjustment
Position Settings | Auto Adjustment
(Only for VGA inputs
Performs auto-adjust function on the image.
Horizontal/Vertical Position
Position Settings | Horizontal/Vertical Position
(Only for VGA inputs)
Used to alter placement of the image.
Phase
Position Settings | Phase
(Only for VGA inputs)
This function is a slider to adjust the sampling phase of the analog interface. For optimum image quality, input
pixels should be sampled at the ideal sampling points.
Clocks/Line
Position Settings | Clocks/Line
(Only for VGA inputs)
This function is a slider to adjust the sample clock of the analog interface.
Advanced
Position Settings | Advanced
(Only for VGA inputs)
This function can be used to manually force some of the widely used difficult-to-detect modes which can be
misinterpreted by the controller.
1080p
Position Settings | 1080p
(Only for graphics mode of HDMI)
Select Video or Graphics optimization for 1080p content.
