Sony Ericsson K770 - Front Cover Assembly Replacement; Frame Assembly Replacement; Keypad Support Plate Assembly Replacement

Working Instruction, Mechanical
3/000 21-1/FEA 209 544/142 A
Company Internal
© Sony Ericsson Mobile Communications AB
13(38)
3.1 Battery Cover
Follow the 2.1.1 Disassembly instructions!
Prepare the new battery cover.
Follow the 4.1.5 Reassembly instructions!
3.2 Memory Stick Micro (M2) 128 MB
Follow the 2.1.2 Disassembly instructions!
Prepare the new memory stick (M2) 128 MB.
Follow the 4.1.4 Reassembly instructions!
3.3 Front Cover Assembly
Follow the 2.1.1 – 2.1.3 Disassembly instructions!
Prepare the new front cover assembly.
Follow the 4.1.3 Reassembly instructions!
3.4 Frame Assembly
Follow the 2.1.1 – 2.1.4 Disassembly instructions!
Prepare the new frame assembly.
Follow the 4.1.2 Reassembly instructions!
3.5 Keypad support plate Assembly
Follow the 2.1.1 – 2.1.5 Disassembly instructions!
Prepare the new Keypad support plate Assembly.
Follow the 4.1.1 Reassembly instructions!
