2.1.3 Front Cover Assembly
Use torx screwdriver to remove the four screws marked with
a red ring.(4pcs)
And use cross screwdriver to remove the six screws
marked with a yellow ring.
Unlock the side snaps with the front opening tool when
disassembling the front cover from the PCBA unit.
Separate the front cover assembly from the module.
