Sony Ericsson K770 - Battery Cover and Battery Removal

Working Instruction, Mechanical
3/000 21-1/FEA 209 544/142 A
Company Internal
© Sony Ericsson Mobile Communications AB
7(38)
2.1.1 Battery Cover Assy & Battery
Battery cover key.
Shift the battery cover key.
Lift the battery cover assy down and release it from the
frame assembly.
Release the battery at the bottom and remove it.
