Help Guide
Interchangeable Lens Digital Camera
ILCE-7CM2 α7CII
Bottom
Using the Grip Extension GP-X2 (sold separately)
Greater holding ability can be achieved by attaching the Grip Extension to the camera.
How to attach the Grip Extension
Replacing the battery of the camera
Battery insertion slot1.
Lock lever2.
Battery cover3.
Tripod socket hole
Supports 1/4-20 UNC screws
Use a tripod with a screw less than 5.5 mm (7/32 inches) long. Otherwise, you cannot firmly secure the camera, and
damage to the camera may occur.
4.
Align the locating pin (A) on the Grip Extension with the locating pin hole (B) on the bottom of the camera.1.
Turn and fasten the camera fixing screw (C) while pushing it into the tripod screw hole on the camera.2.
