Sony a7CII User Manual

Help Guide
Interchangeable Lens Digital Camera
ILCE-7CM2 α7CII
FE 28-60mm F4-5.6
Specifications
Focal length: 28 – 60 mm
35mm equivalent focal length
*1
: 42 – 90 mm
Lens groups-elements: 7 – 8
Angle of view 1
*2
: 75° – 40°
Angle of view 2
*2
: 54° – 27°
Minimum focus
*3
: 0.3 – 0.45 m (0.99 – 1.48 ft.)
Maximum magnification: 0.16×
Minimum aperture: f/22 – f/32
Filter diameter: 40.5 mm
Dimensions (max. diameter × height): Approx. 66.6 mm × 45 mm (Approx. 2 5/8 inches × 1 13/16 inches)
Mass: Approx. 167 g (Approx. 5.9 oz.)
SteadyShot: No
Focusing ring1.
Zooming ring2.
Focal-length scale
When shooting, rotate the zooming ring until the focal-length index comes within the focal-length scale range (A) to
extend the lens.
3.
Lens mount rubber ring4.
Mounting index5.
Lens contacts*6.
Lens retraction index
After shooting, rotate the zooming ring until the lens retraction index reaches the focal-length index to retract the
lens.
7.
Focal-length index8.
Do not touch this part directly.
*
This is the equivalent focal length in 35mm format when mounted on an Interchangeable Lens Digital Camera equipped with an APS-C sized
image sensor.
*1
Angle of view 1 is the value for 35mm cameras, and angle of view 2 is the value for Interchangeable Lens Digital Cameras equipped with an
APS-C sized image sensor.
*2
50

Sony a7CII Specifications

General

Effective Megapixels	33.0 MP
ISO Sensitivity	100-51200 (expandable to 50-204800)
Autofocus System	Fast Hybrid AF (phase-detection AF / contrast-detection AF)
Image Stabilization	5-axis in-body image stabilization
Continuous Shooting	Up to 10 fps
Dimensions	124.0 x 71.1 x 63.4 mm
Image Processor	BIONZ XR
Sensor Type	Full-frame CMOS
Video Recording	4K 60p
Viewfinder	0.39-type electronic viewfinder
LCD Screen	3.0-inch vari-angle touchscreen
Connectivity	Wi-Fi, Bluetooth, USB Type-C
Weight	514 g (with battery and memory card)
Memory Card Slots	1 (SD/SDHC/SDXC, UHS-II compatible)
