BDP-BX2/S360
10-1-3. MAIN CHASSIS SECTION
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
101 1-474-150-11 REGULATOR, SWITCHING (SRV2180UC)
(BX2/S360: US, CND)
101 1-474-150-41 REGULATOR, SWITCHING (SRV2183WW)
(S360: PX)
102 A-1704-509-A MB-127 BOARD, COMPLETE (S360: US, CND)
102 A-1704-510-A MB-127 BOARD, COMPLETE (BX2)
102 A-1733-662-A MB-127 BOARD, COMPLETE (S360: PX)
103 A-1703-666-A USB-014 BOARD, COMPLETE
104 2-319-429-01 CUSHION, FOOT
not supplied
(+BV3)
not supplied
(+BV3)
not supplied
not supplied
(+BV3)
not supplied
not supplied
(+BV3)
101
102
103
104
not supplied
not supplied
(+BV3)
The components identified by mark
or dotted line with mark are
critical for safety.
Replace only with part number
specified.
