2-1
BDP-BX2/S360
SECTION 2
DISASSEMBLY
• This set can be disassembled in the order shown below.
2-1. DISASSEMBLY FLOW
Note: Follow the disassembly procedure in the numerical order given.
2-2. UPPER CASE
2-2. UPPER CASE
(Page 2-1)
2-3. FRONT PANEL ASSY
(Page 2-2)
2-4. BD DRIVE
(Page 2-2)
2-5. REAR PANEL BLOCK
(Page 2-3)
2-7. SWITCHING REGULATOR
(Page 2-4)
2-6. MB-127 BOARD
(Page 2-3)
SET
1 tapping screw
(tightening torque = 5.5 to 7.5 kgf•cm)
1 tapping screw
(tightening torque = 5.5 to 7.5 kgf•cm)
2 three screws
(tightening torque = 5.5 to 7.5 kgf•cm)
3 upper case
