BDP-BX2/S360
Pin No. Name I/O Description
J23 GND - Ground for digital and DDR2 SDRAM
J24 TMODE3 I Not used (Fixed at "L")
J25 TMODE5 I Not used (Fixed at "L")
J26 VRVDD - 1.05V supply for VR5500 PLL
J27 VRGND - Ground for VR5500 PLL
J28 GPIO11 I/O FORMAT1 (480="0" 720, 1080="1")
J29 GND - Ground for digital and DDR2 SDRAM
J30 SCL0 I/O I2C I/F 0 Serial Clock
J31 GND - Ground for digital and DDR2 SDRAM
J32 VDD3 - 3.3V supply (I/O buffers)
J33 GND - Ground for digital and DDR2 SDRAM
J34 HDVSS - Analog ground for HDMI
J35 HDVSS - Analog ground for HDMI
K1 X1 I Crystal Input
K2 PC1 I/O General Port I/F
K3 SFCS0B O Flash Memory I/F Serial Memory Chip Select
K4 SFSIO0 I/O Flash Memory I/F Serial Data Input/Output
K5 PB4 I/O General Port I/F
K6 DVDD15 - Digital 1.5V supply for Drive Controller Block
K7 PTEST28 O Test I/F (HIOCS16B)
K8 PA5 I/O General Port I/F
K9 MD0 I/O External SDRAM I/F Memory Data Input/Output
K10 VOID - This pin is not ball.
K11 VOID - This pin is not ball.
K12 VOID - This pin is not ball.
K13 VOID - This pin is not ball.
K14 VOID - This pin is not ball.
K15 VOID - This pin is not ball.
K16 VOID - This pin is not ball.
K17 VOID - This pin is not ball.
K18 VOID - This pin is not ball.
K19 VOID - This pin is not ball.
K20 VOID - This pin is not ball.
K21 VOID - This pin is not ball.
K22 VOID - This pin is not ball.
K23 VOID - This pin is not ball.
K24 VOID - This pin is not ball.
K25 VOID - This pin is not ball.
K26 VOID - This pin is not ball.
K27 VDD10 - 1.05V supply (core)
K28 VDD10 - 1.05V supply (core)
K29 GND - Ground for digital and DDR2 SDRAM
K30 GND - Ground for digital and DDR2 SDRAM
K31 VDD3 - 3.3V supply (I/O buffers)
K32 VACOMPYC - Compensation capacitance
K33 HDVSS - Analog ground for HDMI
K34 HTXP2 O HDMI TMDS Data Output 2+
K35 HTXN2 O HDMI TMDS Data Output 2-
L1 DGND - Digital GND for Drive Controller Block
L2 PC2 I/O General Port I/F
L3 SFSIO1 I/O Flash Memory I/F Serial Data Input/Output
L4 SFSCK O Flash Memory I/F Serial Interface Clock Output
L5 DVDD15 - Digital 1.5V supply for Drive Controller Block
L6 DGND - Digital GND for Drive Controller Block
L7 PTEST17 I/O Test I/F (DASPB)
L8 PB5 I/O General Port I/F
L9 MD14 I/O External SDRAM I/F Memory Data Input/Output
L10 VOID - This pin is not ball.
L11 VOID - This pin is not ball.
L12 VOID - This pin is not ball.
L13 VOID - This pin is not ball.
