10-6
BDP-BX2/S360
10-2. ELECTRICAL PARTS LIST
NOTE:
• Due to standardization, replacements in the parts
list may be different from the parts specified in
the diagrams or the components used on the
set.
• -XX and -X mean standardized parts, so they
may have some difference from the original
one.
• RESISTORS
All resistors are in ohms.
METAL: Metal-film resistor.
METAL OXIDE: Metal oxide-film resistor.
F: nonflammable
• Items marked “*” are not stocked since they are
seldom required for routine service.
Some delay should be anticipated when ordering
these items.
• SEMICONDUCTORS
In each case, u: µ, for example:
uA. . : µA. . uPA. . : µPA. .
uPB. . : µPB. . uPC. . : µPC. .
uPD. . : µPD. .
• CAPACITORS
uF: µF
• COILS
uH: µH
• Abbreviation
CND : Canadian model
The components identified by mark or dotted
line with mark are critical for safety.
Replace only with part number specified.
Les composants identifiés par une marque
sont critiquens pour la sécurité.
Ne les remplacer que par une pièce portant le
numéro spécifié.
When indicating parts by reference number,
please include the board.
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
A-1703-664-A FL-193 BOARD, COMPLETE
*********************
(Ref. No. 20,000 Series)
< CONNECTOR >
CN331 1-770-160-21 PIN, CONNECTOR (PC BOARD) 2P
< SWITCH >
S331 1-771-410-21 SWITCH, TACTILE (I/1)
A-1703-662-A FR-301 BOARD, COMPLETE
**********************
(Ref. No. 20,000 Series)
< CAPACITOR >
C701 1-115-339-11 CERAMIC CHIP 0.1uF 10% 50V
C703 1-125-972-91 ELECT 100uF 20% 16V
C704 1-124-589-11 ELECT 47uF 20% 16V
C707 1-107-726-91 CERAMIC CHIP 0.01uF 10% 16V
C711 1-115-339-11 CERAMIC CHIP 0.1uF 10% 50V
C712 1-128-131-11 ELECT 22uF 20% 50V
C713 1-115-339-11 CERAMIC CHIP 0.1uF 10% 50V
C714 1-107-726-91 CERAMIC CHIP 0.01uF 10% 16V
C715 1-107-726-91 CERAMIC CHIP 0.01uF 10% 16V
C716 1-115-339-11 CERAMIC CHIP 0.1uF 10% 50V
C717 1-164-217-11 CERAMIC CHIP 150PF 5% 50V
C718 1-164-217-11 CERAMIC CHIP 150PF 5% 50V
< CONNECTOR >
CN701 1-793-806-51 CONNECTOR, FFC/FPC 17P
< DIODE >
* D701 6-502-466-01 DIODE CL-270S-WS-SD-TS
(BLU-RAY DISC INDICATOR)
D703 8-719-988-61 DIODE 1SS355TE-17
D704 8-719-988-61 DIODE 1SS355TE-17
D705 8-719-988-61 DIODE 1SS355TE-17
D706 8-719-988-61 DIODE 1SS355TE-17
D707 6-501-726-01 DIODE MAZ8047GMLS0
< IC >
IC701 6-600-665-01 IC GP1UE27XK0VF
IC702 6-701-729-01 IC PT6315
< COIL >
L701 1-411-919-11 INDUCTOR 100uH
< FLUORESCENT INDICATOR TUBE >
ND701 1-483-022-11 INDICATOR TUBE, FLUORESCENT
< IC LINK >
PS701 1-576-122-21 IC LINK 0.4A 72V
< TRANSISTOR >
Q703 8-729-421-19 TRANSISTOR UN2213
Q704 8-729-904-87 TRANSISTOR 2SB1197K-R
Q706 8-729-901-88 TRANSISTOR 2SC2411K-CR
Q707 8-729-901-88 TRANSISTOR 2SC2411K-CR
Q708 8-729-421-19 TRANSISTOR UN2213
Q709 8-729-904-87 TRANSISTOR 2SB1197K-R
Q710 8-729-421-19 TRANSISTOR UN2213
Q711 8-729-421-19 TRANSISTOR UN2213
< RESISTOR >
R701 1-216-833-11 METAL CHIP 10K 5% 1/10W
R702 1-216-033-00 METAL CHIP 220 5% 1/10W
R705 1-216-821-11 METAL CHIP 1K 5% 1/10W
R707 1-216-828-11 METAL CHIP 3.9K 5% 1/10W
R712 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R713 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R714 1-216-838-11 METAL CHIP 27K 5% 1/10W
R715 1-216-845-11 METAL CHIP 100K 5% 1/10W
R717 1-216-033-00 METAL CHIP 220 5% 1/10W
R718 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R719 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R720 1-216-805-11 METAL CHIP 47 5% 1/10W
R721 1-216-833-11 METAL CHIP 10K 5% 1/10W
FR-301FL-193
The components identified by mark contain
confidential information.
Strictly follow the instructions whenever the
components are repaired and/or replaced.
Les composants identifiés par la marque con-
tiennent des informations confidentielles.
Suivre scrupuleusement les instructions
chaque fois qu’un composant est remplacé et
/ ou réparé.
