Sony BDP-BX2 - Front Panel Assy; BD Drive

2-2
BDP-BX2/S360
2-3. FRONT PANEL ASSY
2-4. BD DRIVE
1 seven claws
2 front panel assy
7 four screws (BV3)
(tightening torque = 5.5 to 7.5 kgf•cm)
8 BD drive
1 non-halogene tape
2 harness (PM-156)
(CN2)
4 flexible flat cable
(CN4261)
5 flexible flat cable
(CN4201)
6 flexible flat cable
(CN1301)
3 harness (PM-157)
(CN3)
