6-5
BDP-BX2/S360
Pin No. Name I/O Description
G32 VDD3 - 3.3V supply (I/O buffers)
G33 GND - Ground for digital and DDR2 SDRAM
G34 VAR O Component Output either R or Pr Signal
G35 GND - Ground for digital and DDR2 SDRAM
H1 DGND - Digital GND for Drive Controller Block
H2 DVDD15 - Digital 1.5V supply for Drive Controller Block
H3 SDIO I/O General Serial I/F Input/Output Data
H4 SDCS0B O General Serial I/F Channel #0 Select Signal
H5 SDCS2B I/O General Serial I/F Channel #2 Select Signal
H6 PA3 I/O General Port I/F
H7 PA1 I/O General Port I/F
H8 WALPF1 I/O Connection to condenser for WAPLL
H9 RFTST2/SWRF2/RFP2 O RF I/F RF Test Output/SWRF2 Output/GPIO 2
H10 CWHP I/O RF I/F Connection to condenser for WOBBLE circuit HPF
H11 MD12 I/O External SDRAM I/F Memory Data Input/Output
H12 WEB O External SDRAM I/F Memory Write Enable
H13 MCLKOUT O External SDRAM I/F SDRAM Clock Output
H14 MD7 I/O External SDRAM I/F Memory Data Input/Output
H15 MD6 I/O External SDRAM I/F Memory Data Input/Output
H16 GPIO20 I GPIO20
H17 N.U. I/O Not used
H18 SAGNDDIG - Digital ground for Serial ATA
H19 SAGNDDIG - Digital ground for Serial ATA
H20 PVDD - 1.05V supply for PLL
H21 PGND - Ground for PLL
H22 RSTSWB I Hardware Reset (L: RESET)
H23 TMODE4 I Not used (Fixed at "L")
H24 TEST I Not used (Fixed at "L")
H25 TMODE1 I Not used (Fixed at "L")
H26 TMODE0 I Not used (Fixed at "L")
H27 TMODE2 I Not used (Fixed at "L")
H28 GPIO13 I/O ASPECT1 (4:3, 16:9="0" 4:3LB="1")
H29 GPIO58 O GPIO58
H30 SDA1 I/O I2C I/F 1 Serial Data
H31 SDA0 I/O I2C I/F 0 Serial Data
H32 GND - Ground for digital and DDR2 SDRAM
H33 VAC O S-Video C Signal Output
H34 GND - Ground for digital and DDR2 SDRAM
H35 VAG O Component Output either G or Y Signal
J1 X2 I/O Crystal Input/Output
J2 SFSIO2 I/O Flash Memory I/F Serial Data Input/Output
J3 SFSIO3 I/O Flash Memory I/F Serial Data Input/Output
J4 PC0 I/O General Port I/F
J5 PA7 I/O General Port I/F
J6 PA6 I/O General Port I/F
J7 PA4 I/O General Port I/F
J8 MD15 I/O External SDRAM I/F Memory Data Input/Output
J9 MD1 I/O External SDRAM I/F Memory Data Input/Output
J10 MD2 I/O External SDRAM I/F Memory Data Input/Output
J11 MD13 I/O External SDRAM I/F Memory Data Input/Output
J12 LDQM I/O External SDRAM I/F Lower Data Mask Control
J13 UDQM I/O External SDRAM I/F Upper Data Mask Control
J14 MD5 I/O External SDRAM I/F Memory Data Input/Output
J15 MD10 I/O External SDRAM I/F Memory Data Input/Output
J16 GPIO5 I Not Used (Fixed at "H")
J17 GPIO2 O Not Used
J18 SAGNDDIG - Digital ground for Serial ATA
J19 VDD3 - 3.3V supply (I/O buffers)
J20 PVDD - 1.05V supply for PLL
J21 PGND - Ground for PLL
J22 VDD3 - 3.3V supply (I/O buffers)
