6-7
BDP-BX2/S360
Pin No. Name I/O Description
L14 VOID - This pin is not ball.
L15 VOID - This pin is not ball.
L16 VOID - This pin is not ball.
L17 VOID - This pin is not ball.
L18 VOID - This pin is not ball.
L19 VOID - This pin is not ball.
L20 VOID - This pin is not ball.
L21 VOID - This pin is not ball.
L22 VOID - This pin is not ball.
L23 VOID - This pin is not ball.
L24 VOID - This pin is not ball.
L25 VOID - This pin is not ball.
L26 VOID - This pin is not ball.
L27 GND - Ground for digital and DDR2 SDRAM
L28 VDD3 - 3.3V supply (I/O buffers)
L29 GND - Ground for digital and DDR2 SDRAM
L30 VARSETYC - 680-ohm Resister
L31 VAREFRGB - Voltage Reference Input for DAC (1.32V)
L32 HDVSS - Analog ground for HDMI
L33 HDVSS - Analog ground for HDMI
L34 HTXP1 O HDMI TMDS Data Output 1+
L35 HTXN1 O HDMI TMDS Data Output 1-
M1 CLK27OUT O 27MHz Clock output for XTAL
M2 FG I Motor Drive I/F FG Signal Input
M3 PSI5 I/O General Port I/F
M4 PSI3 I/O General Port I/F
M5 PSI1 I/O General Port I/F
M6 DVDD33 - Digital 3.3V supply for Drive Controller Block)
M7 PTEST30 I/O Test I/F (PDIAGB)
M8 DGND - Digital GND for Drive Controller Block
M9 VDD15OSC - Power Supply 1.5V for Oscillator
M10 VOID - This pin is not ball.
M11 VOID - This pin is not ball.
M12 VOID - This pin is not ball.
M13 VOID - This pin is not ball.
M14 VOID - This pin is not ball.
M15 VOID - This pin is not ball.
M16 VOID - This pin is not ball.
M17 VOID - This pin is not ball.
M18 VOID - This pin is not ball.
M19 VOID - This pin is not ball.
M20 VOID - This pin is not ball.
M21 VOID - This pin is not ball.
M22 VOID - This pin is not ball.
M23 VOID - This pin is not ball.
M24 VOID - This pin is not ball.
M25 VOID - This pin is not ball.
M26 VOID - This pin is not ball.
M27 VDD3 - 3.3V supply (I/O buffers)
M28 DVDDYC - 3.3V supply (DAC Digital VDD)
M29 VAREFYC - Voltage Reference Input for DAC (1.32V)
M30 VARSETRGB - 470-ohm Resister
M31 GND - Ground for digital and DDR2 SDRAM
M32 HVDD_IO - 3.3V supply (HDMI Tx I/O)
M33 HDVSS - Analog ground for HDMI
M34 HTXP0 O HDMI TMDS Data Output 0+
M35 HTXN0 O HDMI TMDS Data Output 0-
N1 CLK27IN I 27MHz Clock Input
N2 P53 I/O General Port I/F
N3 DVDD33 - Digital 3.3V supply for Drive Controller Block)
N4 PSI4 I/O General Port I/F
